Name: Grade 1 Surface Door Closer, 180 Degree Opening, ADA Approved
Brand: TELL MANUFACTURING
SKU: 479-1075
Availability: InStock

Grade 1 Surface Door Closer, 180 Degree Opening, ADA Approved

Item No 479-1075

Manufacturer TELL MANUFACTURING

Mfr. Item No DC100018

$95.57

Min Order 4

Unit of Measure EA

Ships in 4-5 days

Description
Additional Details
Purchase History
General Ledger Coding

Some product details generated with AI assistance — verify specs before ordering.

The Tell Manufacturing DC100018 is a heavy-duty Grade 1 surface-mounted door closer engineered for high-traffic commercial applications. This ADA-compliant closer features a durable aluminum body and a forged steel arm, supporting a full 180-degree opening for maximum accessibility. It is UL/ULC listed for up to 3 hours of fire-rated performance and has been tested for 2 million cycles to ensure long-term reliability. The versatile tri-pack mounting system allows for regular, top jamb, or parallel arm installations, while adjustable spring power (sizes 1-4) and independent valves for sweep and latch speeds provide precise control.

Grade 1 surface applied closers. Complies with ANSI A156.4, Grade 1, 2 million cycles, UL/ULC listed up to 3 hrs fire rated performance. Non-handed. Tri-pack mounting - regular, top jamb and parallel arm applications. Spring power adjustable 1 - 4 and 3 - 6 sizes. Adjustable back check, hydraulic - providing cushioning and preventing uncontrolled openings of the door. Adjustable valves, independent, non-critical (sweep and latch), consistent closing speeds. Metal screws fasteners included for hollow metal and aluminum mounting applications. Wood screws included for wood door mounting applications. Thru-bolts optional. Door range up to 180 deg. Door Preparation: 9-1/16 in horizontal and 3/4 in vertical mounting hole locations (retrofits traditional closer).

Packaging/Shipping Size and Weight: Length: 12.75" | Width: 4.5" | Height: 3.5" | Weight: 1.5 lbs

Product Details
Brand:	Tell Manufacturing
Product Type:	Door Closer
Mounting Type:	Tri-pack (Regular, Top Jamb, Parallel Arm)
Handing:	Non-handed
Door Opening:	Up to 180°
Grade:	Grade 1
Certifications:	ANSI A156.4; UL/ULC Listed
Fire Rating:	UL/ULC Listed up to 3 Hours
Cycle Rating:	2 Million Cycles
Adjustability:	Adjustable spring power; adjustable backcheck; adjustable sweep & latch speeds
Application:	Regular arm, top jamb, or parallel arm door closer installations
Included Hardware:	Metal screws for hollow metal/aluminum; wood screws for wood doors
Door Preparation:	9-1/16 in horizontal and 3/4 in vertical mounting hole locations
Color:	Silver
Finish:	Aluminum
Material:	Aluminum Body, Steel Arm
Compliance:	ADA Approved, ANSI A156.4
Opening Range:	180 Degrees
Spring Size:	Adjustable 1-4
